installation
FINISHING
For finishes using non-combustible facings, the
materials may overlap the frame of the fireplace
up to within
‘iz”
of the opening on either side. It
should not extend below Line C (Fig. 9) above the
fireplace opening. The finished materials may be
anchored using metal
screws
into the fireplace
frame.
. The framing of the fireplace
May
be covered with
any non-combustible facing material,
1.e..
light-
weight stone, brick, veneer, ceramic tile, etc.
CAUTION
Do not block off the circulating air opening
at
the bottom front of the fireplace.
TO
FUSE
Framing
1
OR
CURCUlT
STUDS
BREAKEll
HEADER
\
-
---
NOT
SVPPLED
OPTIONAL BLOWER
WIRING DIAGRAM
24”
TO REMOVE FRONT BOTTOM
GRILLE TO INSTALL BLOWER, RE-
MOVE THESE SCREWS LIFT PANEL
UP AND OUT.
KNOCKOUT
FOR
OUTSIDE AIR
An electric junction box (with grounded receptacle)
is located
at
the lower
riaht.
behind the bottom
grille
(Fig.
IO).
This is for use
with
the optional
bloweronly
(Page 15). The front of bottom grille may be removed
by unscrewing three screws in grille and lifting grille
up and out (Fig. 10). Electrical wiring connections may
be made through the wiring access plate without re-
moval of receptacle or grille,
Wire the receptacle into an electrical circuit during
the framing of the fireplace. A U.L. listed AC general
use wall switch rated at 15 Amp. 125 VAC minimum
may be used in the circuit or the speed control sup-
plied with blower. The fireplace junction box has a
ECEPTICLC
FOR USE
WITH
)PTlONAL
BLOWER
/
wiring access plate, next
+o
the
%”
hole provided for
connection of an electric wire fitting. Refer to wiring
diagram above. Locate the switch in a wall box close
to
the fireplace.
Installation of wiring
mus:
comply with the Na-
tional Electrical Code and <II local codes and their
requirements. The wiring should be installed by a
qualified person.
Secure fireplace in place with blocks nailed to floor.
IMPORTANT: For your safety and protection, the fire-
place and chimney should be grounded. Use a ground
rod, clamp and wire or other means to ground fireplace
and chimney, Consult codes having jurisdiction.
7
