Fault Codes
The battery condition meter will flash fault codes when the controller system detects an abnormal
condition in the electrical system. All of the battery condition meter LEDs will flash a number of times
quickly, then pause, then flash again. The battery condition meter will continue to flash the fault codes
until the problem is fixed. The table below identifies the individual fault codes. If any of these fault codes
persist, contact your authorized Pride Provider.
Fault Codes Probable Causes Possible Solutions
1 Flash The batteries need charging.
There is a bad connection to the
batteries.
Check the battery connections. If the
battery connections are good, then try
charging the batteries.
2 Flashes There is a bad connection on the left
motor.
Check the left motor connections and
wiring harnesses.
3 Flashes The left motor has a short to the
battery connection.
Contact your authorized Pride Provider.
4 Flashes There is a bad connection on the
right motor.
Check the right motor connections and
wiring harnesses.
5 Flashes The right motor has a short to a
battery connection.
Contact your authorized Pride Provider.
Scroll Left
to Right
The charge inhibit has been
activated.
Make sure that the battery charger is not
connected to the power base.
7 Flashes There is a joystick fault. Make sure the joystick is in the center
position and then power off and on again.
8 Flashes There is a control system fault. Check power module and joystick module
connections and wiring.
9 Flashes The park brakes have a bad
connection.
Ensure that both freewheel levers are in
drive mode. Check the left and right motor
connections and wiring.
10 Flashes An excessive voltage has been
applied to the control system.
Check the battery connections.
Left red LED
flashes 4 times
in 0.5-second
intervals at power
down.
Power chair has been driven for 8
hours or more and the batteries have
not been charged.
Fully charge the batteries for 8 to 14 hours.
The controller must be powered on during
charge cycle.
Care and Maintenance
Refer to your power chair owner’s manual for proper cleaning and disposal instructions.
Warranty
Refer to your power chair owner’s manual for specific information on controller warranty.
