8
Figure 3. Control Panel
JOYSTICK
SPEED DIAL
ON/OFF KEY
BATTERY CONDITION METER
HORN KEY
Control Panel
The control panel is located directly in front of the joystick. It contains keys and a dial that you will use
to control your power chair. See figure 3.
On/Off Key
The on/off key turns the system on and off.
WARNING! When faced with an emergency situation, release the joystick, then press the on/off to
stop the power chair. Use caution. Be advised that pressing the on/off button may cause the power
chair to stop abruptly.
WARNING! Always turn the power off when you are stationary to prevent unexpected movement.
Horn Key
The horn key activates a warning horn.
