34 www.pridemobility.com Jazzy EVO Series
VII. CARE AND MAINTENANCE
Figure 20. Lithium Battery Installation (Seat Removed for Clarity)
1. Rear Shroud
2. Top Shroud
3. Battery
4. Thumbscrews
Identification Key
1
4
2
3
BATTERY SET CONFIGURATION:
+ = POSITIVE (RED) TERMINAL POST
- = NEGATIVE (BLACK) TERMINAL POST
CONNECT RED WIRE TO RED
POSITIVE (+) TERMINAL POST.
CONNECT BLACK WIRE TO BLACK
NEGATIVE (-) TERMINAL POST.
