18 www.pridemobility.com Jazzy Select 7
III. YOUR POWER CHAIR
Specifications
Suspension: Active-Trac Suspension
Drive Wheels: 10 in.(25.4 cm), solid, center-mounted
Caster Wheels: 8 in. (20.32 cm), solid, rear articulating
Anti-Tip Wheels: 6 in. (15.24 cm), solid, front mounted
Maximum Speed:¹ Up to 4 mph (6.43 km/h)
Range:¹ Up to 14 miles (22.53 km)
Brakes: “Intelligent Braking,” electronic regenerative, disc park brake
Ground Clearance:² 2.5 in. (6.35 cm)
Turning Radius:² 18.5 in.(47 cm)
Overall Size:² Length: 36.5 in. (92.71 cm)
Width: 23 in. (58.42 cm) assembled
Drivetrain: Two motor, mid-wheel
Batteries:³ Two 12-volt, deep-cycle U-1 batteries
Battery Charger: 3-amp, Onboard
Weight Capacity: 300 lbs. (136 kg)
Component Weights: Seat: 33 lbs. (14.97 kg)
Foot Platform: 8.5 lbs. (3.85 kg)
Front Battery and Case: 26 lbs. (11.79 kg) (U-1 Battery: 24.5 lbs. (11.11 kg)
Rear Battery and Case: 26 lbs. (11.79 kg) (U-1 Battery: 24.5 lbs. (11.11 kg)
Service Component Frame Assembly: 93 lbs. (42.18 kg)
Weights: Battery Well Frame: 13.5 lbs. (6.12 kg)
Front Frame: 2.5 lbs. (1.13 kg)
Right Frame Assembly: 38 lbs. (17.23 kg)
Left Frame Assembly: 38 lbs. (17.23 kg)
Service Disassembly Bracket: 1 lb. (.45 kg)
¹ Varies with base model, user weight, terrain type, battery amp hour rating (Ah), battery charge, battery condition,
motors, controller type, tire type, and tire condition.
² Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance
of (+ or – ) 3%.
³ AGM or Gel-Cell type required. See VII. “Batteries and Charging”.
NOTE: All specifications subject to change without notice.
