Pride Mobility Jazzy Select Series - Page 9

Jazzy Select Series www.pridemobility.com 9
III. YOUR POWER CHAIR
3
1
7
5
2
4
6
Figure 3. The Jazzy Select 6 Power Base
1. Rear Shroud
2. Seat Post
3. Front Cover
4. Main Circuit Breaker
5. Front Anti-Tip Wheels
6. Controller Connector
7. Rear Caster Wheels
Identification Key
