14 www.pridemobility.com Jet 2 HD
III. YOUR POWER CHAIR
SEATBACK
ARMRESTS
JOYSTICK
BODY SHROUD
Figure 5. The Jet 2 HD
FOOT PLATFORM
DRIVE WHEEL
ANTI-TIP WHEELS
CASTER WHEEL
SEAT ASSEMBLY
THE JET 2 HD
The Jet 2 HD has two main assemblies: the seat and the power base. See figures 5 through 7. Typically, the seating
assembly includes the armrests, seat-back, seat base, and a controller. The power base assembly includes two
motor/brake assemblies, two gearboxes, two drive wheels, two anti-tip wheels, two rear casters, two batteries,
and all wiring harnesses.
CONTROLLER
SEATBASE
POWER BASE
ASSEMBLY
