34
Legend
FIGURE 19. DISCONNECTING THE FRONT-TO-REAR
HARNESS
FIGURE 20. DISCONNECTING THE 2-PIN BATTERY
HARNESSES
FIGURE 24. LIFT UP FRAME LOCK LEVER TO UNLOCK
FIGURE 25. SEPARATING THE FRAME
FIGURE 23. REMOVE BALL DETENT PINS
FIGURE 21. BATTERY REMOVAL
FIGURE 22. DISCONNECTING THE MOTOR HARNESS
IX. DISASSEMBLY AND ASSEMBLY
MOTOR HARNESS
