Quantum 600 Series www.pridemobility.com 7
II. SAFETY
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive
conditions.
Keep tools and other metal objects away from battery terminals. Contact with tools
can cause electrical shock.
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and
new batteries. Always replace both batteries at the same time.
Battery Set Configuration:
+ = Positive (Red) Terminal Post
ā = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Posts
Connect Black wires to Black Negative (ā) Terminal Posts
Explosive conditions exist!
Pinch/Crush point.
