18
www.pridemobility.com Revo
Turning Radius
32.25"-34.25"
12"
17"-19"
2.25"
3-wheel 43.25"
4-wheel 44.75"
3-wheel 38"
4-wheel 50"
21.5"
16"
17"
17.24"
IV. SPECIFICATIONS
Figure 4. Scooter Dimensions
Figure 4A. Front Tire Dimensions
2"
8"
3"
9"
Figure 4B. Rear Tire Dimensions
