Pride Mobility S34P - Technical Specifications

8
TECHNICAL SPECIFICATIONS
MODEL
S34P
WEIGHT CAPACITY
115 KG (250 lbs)
SEAT: TYPE/SIZE
16" Fish-on
DRIVE WHEEL
200mmx50mm(8"x2")
FRONT CASTER (WHEEL)
180mmx40mm(7"x1.6")
REAR CASTER (ANTI-TIPPER)
YES
MAX SPEED
6 KM/H
BATTERY SPECIFICATIONS
24V 11.5Ah Li-Polymer / 12V 12AHX 2 pcs
BATTERY RANGE
20km (Lithium) / 15 Km (Lead acid)
CHARGER TYPE
2.5Amp,110/240 Volt, Li-ION Charger
CONTROLLER TYPE
S-DRIVE 45Amp
MOTOR TYPE
4-Pole 270W
WEIGHT: W/ BATTERY
56 lbs(with Li-ion), 70lbs(with sealed lead acid)
WEIGHT: W/O BATTERY
51.4 lbs
TURNING RADIUS
820mm
SUSPENSION
INDEGO SUSPENSION
LENGTH
930mm
WIDTH
485mm
HEIGHT
945mm
Folded Size
750mm*485mm*450mm
SEAT WIDTH
410mm
SEAT HEIGHT
320mm
SEAT DEPTH
330mm
BACK HEIGHT
360mm
WHEEL BASE
695mm
GROUND CLEARANCE
60mm
FOOTRESTS
420mm
The scooter travelling range depends on the road
conditions, battery quality and tire pressure
Max Safe Slope: 6 Degree
