44 www.pridemobility.com V10
APPENDIX I - SPECIFICATIONS
22.25 in. (56.5 cm)
18 in.
(45.72 cm)
17 in.
(43.18 cm)
46 in. (116.8 cm)
4 in. (10.16 cm)
39.5 - 42 in. (100.3 - 106.7 cm)
15.25 - 17.75 in.
(38.7 - 45.1 cm)
16.5 - 19 in.
(42 - 48.25 cm)
42 in. (106.68 cm)
Turning Radius
Figure 26. Victory 10 Dimensions
