Backpacker Series www.pridemobility.com 19
IV. OPERATION
PROTECTIVE CHAIN
Your lift system is equipped with a protective chain
that moves along the outer guide of the chain rail
(see figure 18). Ensure that the chain rail is free
of obstruction at all times. If the protective chain
encounters an obstruction or becomes loose, run the
lift to the rear-most position to automatically realign the
lift system.
WARNING! Avoid contact with the protective
chain and chain rail. Ensure that the chain rail
is free of obstruction at all times.
Figure 18. Protective Chain
PROTECTIVE
CHAIN
