III. YOUR POWER CHAIR
THE FUSION
Your power chair has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the seat
assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake
assemblies, two drive wheels, two anti-tip wheels, two caster wheels, two batteries, and wiring harnesses.
POWER
BASE
ASSEMBLY
SEAT
ASSEMBLY
CONTROLLER
DRIVE WHEEL
CASTER WHEEL
Figure 5. The Fusion
SEAT BASE
