25
Outlander www.pridemobility.com
APPENDIX I - SPECIFICATIONS
SPECIFICATIONS
Lift System Dimensions: Overall Height: 58 in. (147.32 cm)
Overall Width: 49.25-56.75 in. (125.73-144.14 cm) from hitch
with platform down
20 in. (50.80 cm) from hitch with platform
folded
Platform Width: 28 in. (71.12 cm)
Maximum Lift Capacity 190 lbs. (86.18 kg) with Class II hitch
350 lbs. (158.75 kg) with Class III hitch
380 lbs. (172.36 kg) with Class IV hitch (with a minimum
tongue weight of 500 lb. [226.80 kg])
Maximum Mobility Device Width 28 in. (71.12 cm)
Maximum Hitch-to-Ground Clearance 21 in. (53.34 cm)
Motor Fully sealed, 12-volt DC
Onboard Battery (Optional) 12-volt, 18 Ah
Charger 110-volt, off-board
