III. YOUR POWER CHAIR
THE QUANTUM 610
The Quantum 610 has two main assemblies: the seat assembly and the power base assembly. See fi gure 1.
Typically, the seat assembly includes the armrests, seatback and seat base. The power base assembly includes two
motor/brake assemblies, two drive wheels, four castor wheels, two batteries and wiring harnesses. See fi gure 1,
2 and 3.
Figure 1. The Quantum 600 Sport
SEAT
ASSEMBLY
POWER BASE
ASSEMBLY
SEATBACK
ARMRESTS
CONTROLLER
SEAT BASE
FRONT RIGGING
(FOOT PLATFORM SHOWN)
CASTOR WHEEL
REAR SHROUD
DRIVE WHEEL
CASTOR WHEEL
