42 www.quantumrehab.com Quantum 610
APPENDIX I - SPECIFICATIONS
QUANTUM 610 SPECIFICATIONS
Suspension: Active-Trac Extreme (ATX)
Drive Wheels: 25.4 cm (10 in.), pneumatic or solid available
Front Castor Wheels: 12.7 cm (5 in.), solid
Rear Castor Wheels: 15.24 cm (6 in.), solid
Maximum Speed:¹ Up to 6.44 km/h (4.0 mph)
Range: Variable up to 18 km (11.18 miles)
Brakes: “Intelligent Braking” electronic regenerative, disc park brake
Ground Clearance:² See figure 30.
Turning Radius:² See figure 30.
Overall Size:² Length: See figure 30.
Length: See figure 30.
Width: See figure 30.
Drivetrain: Two motor, mid-wheel-6 drive
Batteries:³ Two 12-volt, deep-cycle U-1 batteries
Battery Charger: 5-amp, off-board
Weight Capacity: 136 kg (21 Stone, 300 lbs.)
72.58 kg (11 Stone, 160 lbs.) with Synergy Manual Tilt
136 kg (21 Stone, 300 lbs.) with Synergy TRU-Balance Power Positioning Systems
Component Weights: Base: 50.80 kg (112 lbs.) without seat and batteries
Specialty Seat: 16.78 kg (37 lbs.)
Batteries: 11.11 kg (24.5 lbs.) each
¹ Varies with base model, user weight, terrain type, battery amp hour rating (AH), battery charge, battery condition, motors,
controller type, tyre type and tyre condition. This specification can be subject to a variance of (+ or – ) 10%.
² Due to manufacturing tolerances and continued product improvement, this specification can be subject to a variance of (+
or – ) 3%.
³ AGM or Gel-Cell type required. See VI. “Batteries and Charging.”
NOTE: All specifications subject to change without notice.
