ASSEMBLY DIAGRAM 2 USE A PARTNER TO HELP WITH THIS STEP
REMEMBER: Only hand tighten all nuts and bolts until whole machine is assembled
1.
Attach CONNECTPLATE(3) to RIGHT&LEFTBASE(1&2) withBOLTM12*95 (128), WASHER
12(134)andLOCKNUTM12(138).
2.
AttachRAERBASEA (20)toRIGHT&LEFTBASE(1&2)withBOLTM12*95(128),WASHER12
(134)andLOCKNUTM12(138).
3.
AttachRAERBASEB(21)toRAERBASEA(20)withBOLTM12*95(128),WASHER12(134)
andLOCKNUTM12(138).
4.
AttachREARUPRIGH(23)toRAERBASEA(20)withSCREWM12*95(109),WASHER12(134)
andLOCKNUTM12(138).
5.
Attach GUIDE ROD (10) to RAER BASE B (21) with SCREW M10*85 (108) and RUBBER
BUFFER(76).
6.
(See the exploded diagram for more detail.)
AttachALUMINUMWHEEL(146)to FOAMSUPPORT
(25)withBOLTM10*100(120),WASHER10(133)andLOCKNUTM10(137).
7.
Attach ROUND TUBE (30) to FOAM SUPPORT (25)with BOLT M10*100 (120), WASHER 10
(133)andLOCKNUTM10(137).
8.
Attach FOAMSUPPORT(25)toRAERBASEA&RAERBASEB(20&21)with SCREWM12*95
(109),WASHER12(134)andLOCKNUTM12(138).
