Primare CD15 PRISMA - Back-Panel Connections

CD15 Prisma Compact Disc Player User Guide
9
ANALOG OUT
DIGITAL OUT
OPTICAL COAXIAL USB
CON
RS232 IR
IN
OUT
TRIG
LAN
L
R
Analogue
output
Coax
digital
output
Optical
digital
output
Network
status
RS232 IR
in/out
Trigger
in/out
Ethernet
and USB-A
input
Power and fuse
On/off
The following diagram explains the function of each of the
connectors on the back panel:
BACK-PANEL CONNECTIONS
