13. With the circlip pliers remove the bearing retaining circlip within the freehub.
14. Take the correct bearing extractor tool required for the freehub bearings and fit it to the inner bearing of the
freehub. Take the drift and insert this into the back of the freehub, using the dead blow or rubber mallet remove the
inner bearing. The Freehub may need to be rested on the hub support tool oran open vice to the allow the bearing to
rest on enough for the bearing to pass through.
12
