DISASSEMBLY
The following steps goe through the disassembly of the Prime rear hubs, each step should be followed precisely to avoid any
error.
The disc rotor and cassette should be removed prior to any work being carried out.
it is advised that through all the steps in the disassembly that parts should be cleaned and laid out in an orderly format to
help with re-assembly and to prevent any lose of parts.
1. Remove both non-drive side and drive side end caps.
2. Slide the freehub off the axle and place to one side ready to remove the bearings later in the guide. Ensure that the
ratchet spring is not seated in the freehub
