The PrimeLab / front and back
The PrimeLab / replacing batteries
7
Chamber for the16mm
and for the MERCK cuvettes
Chamber for the
24mm cuvette
On / Off button.
Hold for at least 1 second
to switch on/off
Back to main screen
Buttons 1 to 4.
Function according
to display
Rubber protection
plug for power
supply connection
socket, lift at tab
and turn to open
Power supply socket
Battery compartment lid
Use a coin or similar to
fit beneath the tab and
lever up.
Reclose by pushing down
with pressure.
!!! Do not use rechargeable batteries.
Batteries are NOT charged during mains operation!!!
PrimeLab display
(see next page)
