516574_C_PUB_DATE_3_NOV_2009.DOC INSTALLATION AND MAINTENANCE MANUAL 17
6. TROUBLE SHOOTING AIDS
6.1. DOOR FAILS TO OPEN
In case of a power failure or an emergency situation, proceed as follows:
1. before the door is open, check the washing bath and machine parts temperature.
WARNING!
IF TOO HOT DO NOT OPEN! RISK OF BURN OR SCALD INJURIES!
KEEP CHILDREN OFF WHEN THE MACHINE IS IN OPERATION!
When the washing bath is cooled down, find the bolt (fig.6.11.,pos.2) for access to a lever of emergency
door opening on the left bottom side (1) and unscrew it. Pull the lever by a screwdriver (4 mm diameter)
trough the hole in the frame, to open the door.
WARNING!
IF THE WASHING WATER WAS NOT DRAINED OFF, IT WILL RUN OUT THROUGH THE DOOR
OPENING!
Fig. 6.1. Lever of emergency opening the door.
6.2. ERROR INDICATION SHOWN ON DISPLAY
See User's manual, chapter 5.
See the Programming manual chapter „Troubleshooting“.
!
!
