504 766 PUBLICATION DATE 03/02 INSTALLATION AND MAINTENANCE MANUAL 5
1-Motor version 2-Motor version
CAPACITY: 22kg / 50lbs
WASHING FUNCTION
RPM OF THE DRUM:
washing
distribution
low spinning
high spinning
7 - 50 rpm
90 rpm
301 - 860 rpm
42 rpm
90 rpm
435 rpm
860 rpm
G - factor of spinning max. 310 310
HEATING
TYPES OF HEATING:
steam
100 % electric 18 kW
100 % hot water max 90°C / 194°F
ATTACHMENT
OF WATER INLETS:
water pressure
water inlet
0,3 - 0,6 MPa / 44 - 87 PSI
3/4“
OF WATER DRAINAGE:
dimension
capacity
∅ 76 mm / ∅ 3“
150 dm
3
/min / 40 US gal/min
OF STEAM HEATING:
steam attachment
steam pressure
3/4“
0,3 - 0,8 MPa / 44 - 116 PSI
Connections to external liquid soap supply system 1 connection for manifold
(1 - 5, 6 - 10, ... connections) to liquid soap supply
system
Soap hoppers: 3 / 5 5
CONSUMPTION
Mean water consumption: depends on selected programme cca 550 dm
3
/
145 US gal
STEAM CONSUMPTION:
depends on selected programme
Maximum steam consumption
22 kg. cycle
-1
/ 48,51 lbs. cycle
-1
0,024 kg.s
-1
(88 kg.h
-1
) / 0,054 lbs.s
-1
(194 lbs.h
-1
)
WORKING CONDITIONS
ambient temperature
mean ambient temperature in 24 hrs
relative humidity
height above sea level
from +5°C / 41°F to +40°C / 104°F
to +35°C / 95°F
30% ÷ 95% without condensation
to 1000 m
ANCHORING
Bolt: 4 pcs M10
max. static loading (with linen and water)
max. dynamic loading
(alternative stress when extracting)
frequency of dynamic loading
831kg / 1833lbs
± 140 kg / ± 309lbs
14,5 Hz
NOISE
Mean noise level at max. loading: 70,6 dB (A)
maximum dimensions including protruding parts
tab. 3.1 continuation
*
