525928 Instruction AC-reactor FS16-55 RS27-35 P3/15
1) Subject:
Install an AC-reactor on FS16/23/33/40/55, RS27/35.
This kit is suitable for all versions except FS40/55 3x200-240V :
- suitable for FS16/23/33, RS27/35 for all supply voltages (1x208-240V / 3x208-240V / 3x380-
415V+N / 3x380-480V without N)
- suitable for FS40/55 for 3x380-480(+N), but NOT for 3x200-240V.
This will improve machine reliability on poor power supply systems with spikes and dips.
2) Needed tools:
2 Wrenches M13
- For 1-ph inverter : Wires 2,5mm², length 50cm (4Pc, preferably blue and black)
- For 3-ph inverter (FS16-23 / FS33 400V / RS27-35) : Wires 2,5mm², length
50cm (6Pc, preferably black)
- For 3-ph inverter (FS33 200V / FS40 / FS55) : Wires 4mm², length 50cm (6Pc,
preferably black)
Drill Ø10mm (for metal)
Wire cutting and wire stripping pliers
3) Part numbers:
Nr. part number description Quantity
525927 (H616) SERVICE KIT COMPLETE
1 525928 (H956) This service instruction 1
2 525921 (H323) FR-BAL-B-7,5k Power factor reactor 1
3 311902100008 Washer M8 4
4 PRI202000090 Screw M8x16 4
5 310934000008 Nut M8 4
