Primus MB 90 - Page 38

Pub. date Apr 2006 525660 manual addition of Install. and Program. man. 90-180kg, 198-396lb with recycling tanks.doc. 3/6
90kg/198lb=324 90kg/198lb=1251
90kg/198lb=1720
90kg/198lb=2200
90kg/198lb=625
140kg/308lb=330 140k
g
/308lb=1384
140kg/308lb=1990
140k
g
/308lb=2330
140kg/308lb=636
180kg/396lb=374 180k
g
/396lb=1500
180kg/396lb=2110
180k
g
/396lb=2510
180kg/396lb=636
4
3
2
1
52566
1
610
2
250250
90kg/198lb=1500
140kg/308lb=1700 180kg/396lb=1800
90kg/198lb=2340
140kg/308lb=2660 180kg/396lb=2780
2.2. DIMENSIONS OF THE MACHINE
1. Hard cold water inlet
2. Soft cold water inlet
3. Hot water inlet
4. Steam inlet
Fig. 2.2. Placement of components on the machine (dimensions are given in mm)
