A. Attach bottom Plate to the Stand with 4 screws with 5mm Allen wrench. Use screws attached to
the Stand.
B. Attach white Power connection to the plug in of the Stand.
C. Turn around fully mounted Stand.
D. Position the Platform over the center of the stand. Guide Power Cable through center hole.
E. Once the Platform is centered on center of the Stand, secure it with 4 cap screws (8mm x 20mm)
using 6mm L-shaped Allen wrench.
F. Remove cover on the bottom of the Platform. 4 screws need to be removed with screw driver.
G. Put Tension Head on the Platform. Connect 2 cables with the plug ins of the Tension Head. Fix
screw by hand of each cable connector
H. Shows second cable that need to be connected.
I. Slide in the Tension Head onto the platform until it sits flat on the Platform.
