8
Gently lift your monitor to an upright position.
Based on the picture below, place the well assembled stand to the
corresponding slot at the back cover and ensure the rotation shaft is well
attached to the monitor. Gently lift the monitor up and double-check to
ensure that the monitor is well attached. To dismantle, operate by reversing
the installation steps.
Note: Do not lift the screen by holding on the screen to prevent breaking the panel.
The lifting range is 100mm, and the anti-sliding effect should be taken into consideration
when extraction.
Take out the shaft assembly and stand stem. Fasten it with two 11mm
screws as shown in the picture. Then fasten the stand stem and stand base
with one 11mm screw.
