Section 5: Mount Installation
shaft assembly
spacer screws x 4
VESA and mounting accessories are not included.
Open the package, remove the foam from the monitor, and place the monitor on
the foam on a stable, flat table. Remove the shaft assembly.
Take out the four hexagonal spacer screws with a height of 35mm from the
accessory bag, and fasten them into the M4 threaded hole of the rear tank sinking
slot with a screwdriver (not included). It is advised to place the monitor on top of the
foam to prevent breaking the screen.
Install the monitor on the wall mount or bracket as you desired.
