15 EN | ENGLISH
◊ The generator produces enough electric power to cause a serious
shock or electrocution if misused.
◊ Using a generator electrical appliance in wet conditions, such as
rain or snow, or near a pool or sprinkler system, or when your hands
are wet, could result in electrocution. Keep the generator dry.
◊ If the generator is stored outdoors, unprotected from the weather,
check all electrical components on the control panel before each
use. Moisture or ice can cause a malfunction or short circuit in
electrical components which could result in electrocution.
◊ Do not connect to a building’s electrical system unless an isolation
switch has been installed by a qualified electrician.
Fire and Burn Hazards:
◊ The exhaust system gets hot enough to ignite some materials.
Keep the generator at least 1 meter (3 feet) away from buildings and other
equipment during operation.
Do not enclose the generator in any structure.
Keep flammable materials away from the generator.
◊ The muffler becomes very hot during operation and remains hot for
a while after stopping the engine. Be careful not to touch the muffler
while it is hot. Let the engine cool before storing the generator
indoors.
◊ Gasoline is extremely flammable and is explosive under certain
conditions. Do not smoke or allow flames or sparks where the
generator is refueled or where gasoline is stored. Refuel in a well-
ventilated area with the engine stopped.
◊ Fuel vapors are extremely flammable and may ignite after the
engine has started. Make sure that any spilled fuel has been wiped
up before starting the generator.
CONTROL
Engine Switch:
To start and stop the engine.
Switch position:
OFF: To stop the engine. Key can be removed/inserted.
ON: To run the engine after starting.
START: To start the engine by turning the starter motor.
(Pic. 2*)
Recoil Starter:
To start the engine, pull the starter grip lightly until resistance is felt, then
pull briskly.
Do not allow the starter to snap back against the engine. Return it gently to
prevent damage to the starter.
(Pic. 3*)
NOTICE!
Fuel Valve:
The fuel valve is located between the fuel tank and carburetor. When the valve
lever is in ON position, fuel is allowed to flow from the fuel tank to the carburetor.
Be sure to return the lever to OFF after stopping the engine.
(Pic. 4*)
Choke:
The choke is used to provide an enriched fuel mixture when starting a cold
engine. It can be opened and closed by operating the chock lever or choke
rod manually. Move the lever or the rod to CLOSE position to enrich the
mixture.
Circuit Breaker:
The circuit breaker will automatically switch OFF if there is a short circuit
or a significant overload of the generator at the receptacle. If the circuit
breaker is switched OFF automatically, check that the appliance is working
properly and does not exceed the rated load capacity of the circuit before
switching the circuit breaker ON again.
(Pic. 5*)
The circuit breaker may be used to switch the generator power ON or OFF.
(Pic. 6*)
Ground Terminal:
The generator ground terminal is connected to the panel of the generator,
the metal non-current carrying parts of the generator, and the ground
terminals of each receptacle. Before using the ground terminal, consult a
qualified electrician, electrical inspector or local agency having jurisdiction
for local codes or ordinances that apply to the intended use of the
generator.
Oil Alert System:
The oil alert system is designed to prevent engine damage caused by
an insufficient amount of oil in the crankcase. Before the oil level in the
crankcase can fall below a safe limit, the oil alert system will automatically
shut down the engine (the engine switch will remain in ON position). If this
occurs, first check engine oil.
GENERATOR USE
Connections to a Building’s Electrical System:
Connections for standby power to a building’s electrical system must be
made by a qualified electrician. The connection must isolate the generator
power from utility power and must comply with all applicable laws and
electrical codes.
WARNING
Improper connections to a building’s electrical system, can allow electrical
current from the generator to feedback into the utility lines. Such feedback may
electrocute utility company workers or others who contact the lines during a
power outage. Consult the utility company or a qualified electrician.
Improper connections to a building’s electrical system can allow electrical
current from the utility company to feedback into the generator. When
utility power is restored, the generator may explode, burn, or cause fires
in the building’s electrical system.
CAUTION
Ground System:
To prevent electrical shock from faulty appliances, the generator should be
grounded. Connect a length of heavy wire between the ground terminal and the
ground source. The generators have a system ground that connects generator
frame components to the ground terminals in the AC output receptacles. The
system ground is not connected to the AC neutral wire. If the generator is tested
by a receptacle tester, it will show the same ground circuit condition as for a
home receptacle.
AC Applications:
Before connecting an appliance or power to the generator:
◊ Make sure that it is in good working order. Faulty appliances or power
cords can create a potential for electrical shock.
◊ If an appliance begins to operate abnormally, becomes sluggish or
stops suddenly, turn it off immediately. Disconnect the appliance,
and determine whether the problem is the appliance, or if the rated
load capacity of the generator has been exceeded.
◊ Make sure that the electrical rating of the tool or appliance does
not exceed that of the generator. Never exceed the maximum power
rating of the generator. Power levels between rated and maximum
may be used for no more than 30 minutes.
NOTICE
Substantial overloading will switch off the circuit breaker.
Exceeding the time limit for maximum power operation or slightly
overloading the generator may not switch the circuit breaker OFF, but
will shorten the service life of the generator. Limit operation requiring
maximum power to 30 minutes. For continuous operation, do not exceed
the rated power.
In either case, the total power requirements (VA) of all appliances
connected must be considered. Appliance and power tool manufacturers
usually list rating information near the model number or serial number.
AC Operation:
1. Start the engine.
2. Switch the AC circuit breaker ON.
3. Plug in the appliance.
Most motorized appliances require more than their rated wattage for
startup.
Do not exceed the current limit specified for any one receptacle. If an
overloaded circuit causes the AC circuit breaker to switch OFF, reduce the
electrical load on the circuit, wait a few minutes and then reset the circuit
breaker.
DC OPERATION
