TOOL OPERATION
HOW TO INSERT AND REMOVE A BIT
1. To remove a bit from the keyless chuck, hold the “B” part firmly by one hand and turn the “A” part
by counter clockwise.
• Turn counter clockwise. Remove the bit.
• Insert the bit and turn clockwise
2. Forward/Reverse selection button
• Select the forward or reverse direction of the tool by pushing the button.
3. High/Low speed selection
• Use the “High” for drilling application.
• Use the “Low” form screwdriver application.
4. Select the applied torque
• Use the 17 sections adjustment ring to select the right torque for your application.
5. Drill model:
• Select the torque ring to the sign for the maximum torque position if you would like to make
a drill on wood.
A
B
