Pro's Kit GE-897 - 簡易故障排除 Trouble Shooting

32
簡易故障排除 Trouble Shooting
按鍵模組
Keypad Module
圖1
IMAGE 1
Home position起始位置
圖2
3. If Doodler or Sweeper doesn’t execute the program correctly, please check if the robot is set to Mode .
4. If Shooter doesn’t execute the program correctly, please check if the robot is set to Mode .
1. 請確認電池安裝位置是否正確，參見第9頁，步驟 3 .
3. 如創意小畫家/掃地機器人未正確地依循編碼動作，請確認開關位置是否播到模式 .
2. 如創意小畫家/掃地機器人/狙擊神射手未正確地依循編碼動作，請確認左、右齒輪箱和按鍵模組是否組裝正確.
1. Be sure to install batteries with correct polarity, refer to page 9, step .
3
2. If Doodler/Sweeper/Shooter doesn’t execute the program correctly, please check if the left and right gear box
terminals and keypad module are assembled in the correct way.
1
4. 如狙擊神射手未正確地依循編碼動作，請確認開關位置是否播到模式 .
2
6
5. 如創意小畫家無法清楚地畫出線條，請確認筆是否安置於適當位置，參見第15頁，步驟 .
6. 如掃地機器人無法正常掃地，請確認B4是否安裝正確，參見第17頁，步驟 ；第18頁，步驟 .
7. 如狙擊神射手無法直行或正常射擊，請確認齒輪模組A是否安裝正確，參見第23頁，步驟 .
2
1
1
6
2
2
5
5
1
5. If Doodler doesn’t draw clear lines, please check page 15, step .
6. If Sweeper doesn’t clean up appropriately, please check if the part B4 on page 17 step and the part B4 on page 18
step are assembled in the correct way.
7. If Shooter doesn’t go straight or shoot appropriately, please check if the on page 23 step is assembled
in the correct way.
MODULE
A
GEAR
8. 如狙擊神射手的彈簧在射擊後無法回到射擊位置(見下圖1)，請逆時鐘推轉齒輪(見下圖2)
8. If Shooter doesn’t return the spring to home position (image 1 below) after shooting, please push the gear
counterclockwise (image 2 below).
L
齒輪箱模組
左
GEAR BOX
MODULE
R
齒輪箱模組
右
GEAR BOX
MODULE
