拔開端子 Loose the Plug
拆卸技巧 Disassembly Tips
邊扭轉邊拉開 Twist and pull simultaneously.
請如圖示拔開連接電池盒的端子以利拆裝機器人
3
拉開以利鬆脫
Pull and release the parts.
拉開以利鬆脫
Pull and release the parts.
B14
B14
B9
C23
拉開
PULL
拉開
PULL
使用一字起子 Use a screwdriver.
Disassembly Tool : B14 to use on B9 & C23
拆卸工具:使用B14卸下B9或C23(變形時才會用到)
When disassembling the robot, feel free to loose
the plug by pulling the battery case cables as illustrated.
When disassembling the robot, feel free to loose
the plug by pulling the battery case cables as illustrated.
