Pro's Kit MT-1508 - Page 5

4
DC Voltage
Range
Resolution
Accuracy
200mV
0.1mV
± (0.5% readings+3）
2V
0.001V
20V
0.01V
200V
0.1V
600V
1V
±（0.8% reading +5）
Input impedance: 10MΩ
Maximum input voltage: 600V DC or AC RMS
AC Voltage
Range
Resolution
Accuracy
2V
0.001V
±（0.8 reading +3）
20V
0.01V
200V
0.1V
600V
1V
±（1.0% reading +5）
Input impedance: 10MΩ Maximum input voltage: 600V DC or AC RMS.
Frequency range: 40Hz~400Hz;
DC Current
Range
Resolution
Accuracy
200uA
0.1uA
±（1.8% reading +5）
2000uA
1uA
20mA
0.01mA
200mA
0.1mA
Input protection: FF250mA/600V fuse.
AC Current
Range
Resolution
Accuracy
200uA
0.1uA
±（2.0% reading +5）
2000uA
1uA
20mA
0.01mA
200mA
0.1mA
Input protection: FF250mA/600V fuse.
Resistance
Range
Resolution
Accuracy
200Ω
0.1 Ω
±（1.0% reading+3）
2kΩ
0.001 kΩ
20kΩ
0.01 kΩ
200kΩ
0.1 kΩ
2MΩ
0.001MΩ
20MΩ
0.01 MΩ
±（1.2% reading+15）
Input protection: Maximum 600V DC or AC RMS.
