Pro's Kit MT-1510 - Page 9

8
 DC Voltage
Range
Resolution
Accuracy
6V
0.001V
±（0.8% readings +5 digits）
60V
0.01V
600V
0.1V
Min. input voltage 0.8V DC; Overload protection 600V DC or AC RMS.
Input impedance:10M.
 AC Voltage
Range
Resolution
Accuracy
6V
0.001V
±（1.0% readings +5 digits）
60V
0.01V
600V
0.1V
Min. input voltage 0.5V AC; Overload protection 600V DC or AC RMS。
Input impedance:10M.
Frequency range: 40Hz~1000Hz; True RMS
 Frequency
Range
Resolution
Accuracy
10-1000Hz
1Hz
± (2.0% Reading + 5 digits)
6KHz
0.01kHz
Input voltage range: 2V AC valid value.
The frequency is also displayed when the AC voltage or the AC current is measured.
 Resistance
Range
Resolution
Accuracy
600
0.1
±(1.0% Reading +5 digits)
6k
1
60k
10
600k
100
6M
1k
60M
10k
Input protection: 600V DC/AC
 Beeper continuity
Function
Description
Testing environment
When the buzzer sounds, the meas-
ured resistance is less than 50.
Test current: 140A; open circuit
voltage: about 1V.
Input protection: 600V DC/AC
