99.99KHz
0.01 KHz
999.9KHz
0.1 KHz
9.999MHz
0.001MHz
Input voltage range: 200mV-10V ac valid value
Overload protection: 600V DC/AC
4.2.4 Electric resistance
Measuring range
Resolution
Accuracy
600
0.1
±(0.8% Reading + 3 digits)
6k
1
60k
10
600k
100
6M
1k
60M
10k
±(1.2% Reading +30 digits)
Overload protection: 600V DC/AC
Open-circuit voltage: 1V
4.2.5 Diode
Functions
Measurin
g range
Resolution
Testing conditions
Diode test
0-3V
0.001V
Forward DC current:
approximately 1mA;
Open-circuit voltage:
approximately 3.2V.
The display unit shows the
approximate value of the
diode's forward voltage
drop.
Overload protection: 600V DC/AC
4.2.6 Beeper continuity
Functio
ns
Measuri
ng
range
Resolution
Description
Testing
conditions
600
0.1
When the built-in beeper
sounds and the
accompanying green
indicator is on, the
Open-circuit
voltage:
approximatel
y 1V
