Thank your for your purchase of Pro’sKit MT-7028 Network Toner & Probe Kit.
The Toner and Probe set is used to quickly trace and identify cables or wires
within a group and also check the operation of telephone lines. With proper
use and care, this instrument will provide many years of reliable service.
SPECIFICATIONS
MT-7028 Transmitter specifications
Tone frequency
1kHz
Max. distance of transmission
≧3km
Max. distance of cable map
300m
Max. working current
≦65mA
Tone mode
Hi/Low two-note tone
Cable test socket
Test socket : for RJ45(8 pin)/RJ11(6 pin)
cable map test.
RJ45 SCAN socket : for RJ45 locating
individual wire pairs
RJ11 SCAN socket: for RJ11 locating
individual wire pairs
Test Cable types
RJ45 Lan cable Cat 5、5e、6(UTP/ STP)、
RJ11/12 Telephone cable Cat 3
(6P/2C/4C/6C)
Scan Cable types
RJ45 Lan cable Cat 5、5e、6(UTP)、
RJ11/12 Telephone cable Cat 3
(6P/2C/4C/6C)
Function selection
5 Push button switch (POWER、SCAN、
TEST、Ω、POL)
Continuity test
1 LED (≦300Ω), Coaxial cable & normal
solid/Stranded wire by alligator clips patch
cord.
Max. signal voltage
10Vp-p
Cable map indication
8 LEDs, Fast/Slow dual speed
Shielded indication
1 LED
Phone line polarity indication
1 Dual color LED
Live telecommunication
equipment test and router test
Yes
Voltage protection
DC 48V
Auto power off
1 hour
Low battery display
6.5V (Power LED flashes)
Battery type
DC 9.0V (NEDA 1604/ 6F22 DC9V ×1pcs)
