Detailing«UserSetProgram»
ThisscreenallowsyoutochoosethekindofLithiumbatteries.3mainLithiumbatteriesfamilliesexistandare
relatedtoRcmodelapplication:Li‐Po/Li‐Ion/Li‐Fe.Thesebatterieshavedifferentvoltageandcharging
processes.PleasenotethatonlycompatiblerechargeableLithiumbatteriescanbeconnectedtothecharger.
Thisscreenshowsyoutheminimumpowersupplyvoltagethechargerwillacceptbeforecuttingoffanyprocess.
Youcansetavaluebetween10and11Volts.
Youcanchooseheretoenableordisablethekeybipsandchargerindicationsbips.Werecommendyoutokeepon
thechargerBuzzerbeeptobeinformedofanystatechangeduringaprocess
Thisscreenallowsyoutosetupamaximumcapacity(mAh)whichthechargerwillnotgoover,inanycase.Thisis
asupplementarysecurityveryusefullforslowchargeofLeadBatteries.
Youcanenableordisablethesecuritytimer,andsetupamaximumcharge/dischargetime.

Somebatteriescanheatupduringcharge/dischargecycles.Youcaninputhereavalue,inminutes,ofwaitingtime
toletthebatterycooldownbetweentwoprocess,likethecharge/dischargeone.
Thisisthetemperaturesensorcutoffvaluetosetupinthisscreen.Ifthetemperaturesensorisnotconnected,or
defective,thisfunctionisdisabled.
YoucanchooseherethedeltaPeaksensivityforchargeenddetectionNi‐Cdbatteries).Thevaluemustbechoosen
between5and20mV.Ifyouarenotsureaboutthevaluetoenter,pleaseusethe“default”setting.
Sameasabove,butforNni‐Mhbatteries.Standardvalueisaround7mV,butwerecommendyoutomakesome
testsandtousethetemperaturesensorwithaprotectionsetat55°Celsiustostartifyouwanttoincreasethedelta‐
Peakvalue.
ThisscreenindicatesthetimeallowedtotheLithiumbatteriescellsdetection.Inmostcases,afewsecondsare
necessarytodetectthecorrectnumberofcells,butinsomecasesitcanbelonger.Werecommendyoutoleavethe
valueat10mn,andtoalwayscheckthebatterycellsnumberbeforevalidatingthechargerdetectedvalues,andto
changethemifnecessarytomatchtheconnectedbatterypack.
