pro user DIAMANT TG - Fitting the 3 rd Bike Adapter; Pre-Assembly and Adapter Placement

33
FITTING OF THE 3
RD
BIKE ADAPTER TO THE BIKE CARRIER
This expansion set is only suitable for expanding a Pro-User bike
carrier type Diamant TG!
The 3rd bike adapter must be assembled once.
The bike carrier must also be prepared once for the use of the 3rd bike adapter.
Attach the two holders to the wheel holders of the bike carrier.
1
2
3
4
