Water inlet hose connections
Important: This washing machine
MUST only be connected to a
cold water supply.
a: Connect the water inlet hose, the angled
connection attaches to the water inlet on the
back of the washing machine. (7)
b: The straight connection attaches to the water
supply valve. (8)
c: Ensure all seals are in place before
connecting.
Important: Only tighten the hose
connection nut by hand - do not
overtighten.
Drain hose connections
Important: The height of the top
of the curve in the drain hose
MUST be between 60 - 100cm
from the floor. (9)
Important: The end of the water drain hose may
be fitted directly to the waste water outlet hole
or a special apparatus mounted on the outlet
bracket of the wash-stand.
Important: Never attempt to extend the water
drain hose by adding extra parts.
