1514
fig. 25
Filter Cover
Filter Cover
Filter Holder
fig. 26
CLEANING THE FILTERS CLEANING THE FILTERS
NOTE: Failure to keep the filters
clean, will result in a loss of
performance.
NOTE: We recommend cleaning
the Pre-Motor Filter and
Exhaust Filter at the same time
at regular intervals.
3. Remove the Pre-Motor Filter Y
and clean in warm soapy water.
Ensure the Filter is totally dry
before assembly.
See fig. 24.
4. Reinsert the Filter and Dust Tank.
1. Unplug the Cleaner from the mains.
2. Remove the Filter Cover from the
unit.
See fig. 25.
4. Reinsert the Filter and Cover.
See fig. 26.
3. Remove the Exhaust Filter Z from
the Filter Holder. Then clean in
warm soapy water. Ensure the
Exhaust Filter Z is totally dry
before assembly.
See fig. 26.
1. Unplug the Cleaner from the mains.
Changing And Cleaning The Pre-
motor Filter
2. Remove the Dust Tank from the
unit.
See fig. 23.
IMPORTANT:
Never use the appliance without
the motor filter protection and
exhaust filter installed, otherwise
damage to the product may
occur which would not be
covered by the guarantee.
fig. 23
Y
fig. 24
Changing And Cleaning The
Exhaust Filter
Z
NOTE:
Inserting wet filters into the
machine will create an electrical
hazard.
NOTE:
Inserting wet filters into the
machine will create an electrical
hazard.
