OPERATING INSTRUCTIONS
Place pump on horizontal surface or hang it by means of the hook.
Open mattress on the chair. Secure it with straps.
Connect air feed tubes to air outlet on the mattress and pump, ensuring that the
tubes are not kinked or twisted.
Turn on the pump power. The indicator of the power switch will come on. The
pump starts to pump air into the mattress.
The Low Pressure indicator (orange) will come on as inflation undergoes. When
the pressure reaches the preset level within approximately 30 minutes, the
Normal Pressure indicator will come on, and the Low Pressure indicator will turn
off.
Turn the weight adjust knob to set a comfortable weight level.
ENVIRONMENT REQUIREMENTS
Operation Temperature: 50℉~95℉ (10℃~35℃)
Storage Temperature: 5℉~122℉ (-15℃~50℃)
Operation Humidity: 20%~80% non-condensing
Storage Humidity: 10%~90% non-condensing
CLEANING GUIDELINES
Can be cleaned by disinfectant solution.
Do not immerse the pump in water.
Do not heat or steam in autoclave.
The mattress and cover are aerated until they are fully dry.
TECHNICAL SPECIFICATIONS
Pump Mattress
Item: Protekt
®
Aire Geri Chair Overlay
Item: Protekt
®
Aire Geri Chair Overlay
Power supply: 120V/60Hz, 1A
ize: 69" (L) x 20" (W) x 3" (H)
ize: 69" (L) x 24" (W) x 3" (H)
Air output: 9 liter/min.
op cover: Nylon/PU with zipper
Pressure range: 30mmHg–60mmHg
Air cells: Nylon/TPU
Cycle time: 10 min.
ase: Nylon / PVC
Power consumption: 9W
36 air cells
With normal / low pressure light
Quick connectors
Size: 10.83" (L) x 5.31" (W) x 3.54" (H)
WARRANTY: 18 months for pump and mattress
