Proceq DY-2 series User Manual

4 © 2014 Proceq SA
Standard Description Test disc Specified load rate Total
test
time
SIA 281/3 Bitumen sheeting pull-off
testing
dia. 50mm 300
+/- 15 N/s
(Proceq DY-206,
Proceq DY-216
recommended for
elastic surfaces)
JGJ110 Construction Engineering dec-
orative tile Adhesive Strength
Testing Standard
JGJ126 The Exterior Decorative Brick
Construction and Inspection
Acceptance Standard
95x45x8mm,
40x40x8mm
JGJ144 Exterior Insulation Engineering
Technical Standard
100x100x8mm
2.2 Proceq DY-2 Models
Three versions of Proceq DY-2 are available differentiated by maximum pulling force.
• Proceq DY-206 has increased accuracy for low strength applications. Recommended for elastic
surfaces due to higher requirement on load rate.
• Proceq DY-216 covering most applications. Recommended for elastic surfaces due to higher
requirement on load rate.
• Proceq DY-225 required for compliance with ASTM C 1583. Typically used for testing of fibre
reinforced polymers bonded to concrete structures.
The table below shows the recommended working range with a selection of test discs to help you
ascertain which model is most suited to your application.
Working Range Maximum
Pulling Speed
Tensile Force Test Disc Ø 50mm
Proceq
DY-206
0.6 - 6 kN 0.3 - 3.1 MPa
4.65 mm/min
0.183 inch/min
135 - 1349 lbf 44 - 443 psi
Proceq
DY-216
1.6 - 16 kN 0.81 - 8.1 MPa
360 - 3597 lbf 118 - 1182 psi
Proceq
DY-225
2.5 - 25 kN 1.3 - 12.7 MPa 2.2 mm/min
0.086 inch/min
562 - 5620 lbf 185 - 1847 psi
Note: The instrument begins to display and record measurement values from 0 kN.
