PROCRAFT 511307 - Specifications

Page 10


SPECIFICATIONS
Model
Item
511307 511467 511625
Rated input voltage(V)
1 Phase 240V - 50Hz 1 Phase 240V - 50Hz 1 Phase 240V - 50Hz
Rated input current）(A)
24.8 25.6
26
Rated input power (KVA)
27A 33A 38.65A
Wire speed (M/MIN)
2 - 18 2 - 18
0 - 10
Welding current（MMA
10 - 170 20 - 180
-
Welding current）-MIG
40-170
40 - 200
40 - 250
No-load voltage（V） 65V 65V 39V
Duty cycle
120A@100%:
170A@30%
140A @ 100%
170A @ 60%
160A @ 100%
200A @ 60%
Wire diameter (mm)
Ф0.6 - 0.8 - 0.9
Ф0.6 - 0.8 - 0.9 - 1.2 Ф0.6 - 0.8 - 0.9 - 1.2
Welding thickness (mm)
0.6~4.0
0.6~6.0 0.8~10.0
Cover protection
IP21S IP21S IP21S
Insulation
F F F
Dimension
（L×W×H mm）
520 x 330 x 360 520 x 335 x 365 870 x 390 x 610
Weight（kg） 9.5 15 48
