Prodelin 3.8m Antenna Installation Kit
6 Bill Of Materials
Quan Model/Description Manufacturer Comments (Ref Designators)
50’ LA11-50 Electri-Flex 1/2” Liquid Tight Steel Core Flexible Conduit
8 GY-4Q-50 Oz/Gedney 1/2” Straight Conduit Connector
5 GY-4Q-950 Oz/Gedney 1/2” 90 Degree Conduit Connector
1 GY-4Q-450 Oz/Gedney 1/2” 45 Degree Conduit Connector
2 KKR-21 Killark 3/4” to 1/2” Conduit Bushing
1 1/2” Teflon Tape (for conduit fittings)
24’ 8772 cable Belden 3 conductor shielded cable with drain 20 AWG
25’ 01306 Carol 16/3 Motor Connect Cable
32’ 13002 Carol 18/2 Limit Switch Connect Cable
6 Butt Connector Crimp Type, Insulated, 16-14 AWG for Motor
Connections
16 Spade Terminal Crimp Type, Insulated, 22-16 AWG for Limit
Switch Connections
14 UR Connector 3M Red Scotchlok with dielectric grease
16” FIT-221-3/64 Alpha 3/64” heat shrink - Covers Drain Wire at
Sensor Cable Splice
8” FIT-221-1/4 Alpha 1/4” heat shrink - Covers the Break in the
Insulation at the Sensor Cable (Belden 8772)
Splice
6” FIT-221-3/8 Alpha 3/8” heat shrink - Covers the Break in the
Insulation at the Sensor Cable (user supplied)
Splice
8 4” cable tie Tie for Sensor Cable Splice
10 6” cable tie Tie for General Use Inside Interface Box
10 8” cable tie Tie Used to Join Azim/Elev Motor and
Sensor/Limit Conduits (Weather Proof and
Ultraviolet Resistant)
12 9772 Dell City Wire
Co.
Adhesive Cable Tie Point
2 GI752 General
Instrument
High Current Steering Diode for Limit
Switches
2 2 1/2” Jumpers, 16 AWG For Use in Limit Switches
1 Tube of RTV Sealer Used for Misc. Sealing
2 314 012 Littlefuse
12 Amp Ceramic AC Line Fuse for KBPB [1]
2 314 008 Littlefuse
8 Amp Ceramic Armature Fuse for KBPB [1]
1 9841 KB Electronics,
Inc.
0.025 ohm Plug-In Horsepower Resistor for
KBPB-225 Motor Drive Module. This
appropriate for use with the Baldor CDP 3330
1/2 Horsepower, 1750 RPM 90 volt DC motors
used on the Prodelin 3.8 meter antenna.
Note: These fuses are equivalent the Buss type ABC (normal blow, ceramic).
