Start-up Procedures
8
65
7
Flip the toggle switch on the timer box to ON position. The air
compressor should start after 5 seconds. Flush for one cycle and
then replace the stem plugs.
Check the air pressure by looking at the gauge on the air
compressor. The air pressure should be 15-20 PSI (higher
air pressure preferred, but do not exceed 20 PSI). If it’s not
correct, adjust the air pressure on the air compressor with
the allen wrench.
Let the system run for several cycles until all nozzles are spraying.
Check for leaks and ensure proper mist pattern.
Ensure all nozzles are spraying. If not, see
Troubleshooting Guide.
1.5
1
0.5
2.5
2.0
MIST POWER
ON TIME
OFF TIME
7
4
0.5
1.5
11
ON
To Next Page
