System Installation
4
2
IMPORTANT
Make sure to place the control box
near a power and water source.
FLUSH THE CITY WATER LINE FOR
3-4 MINUTES BEFORE CONNECTING
TO OUR WATER LINE.
Tools Required
Material Required
Tube Cutter
Drill
TeonTape
Misc Drill Bits
& Drivers
Adjustable
Wrenches
Chanel Lock
Pliers
Screw Drivers
1
3
Mount the mist control, air compressor and
timer box at the center of the area being
misted on top of the case.
(Other mounting locations can be used.)
OR
Air Curtain
Notch the clamp lock near the middle of the case where
the hole will be drilled to connect water and air lines.
Mount the clamp lock into the case ceiling in
the area to be fogged with the provided screws.
Decide where to mount the clamp lock onto the
case ceiling in the area to be fogged - preferably
inside the air curtain (can
also be placed outside of air
curtain).
To Next Page
