Prodys S.L. Tel: +34 91 6896880 Fax: +34 91 6943777 Email: sales@prodys.net Web: www.prodys.com
Page 37
To go into this menu, just click on ‘Menu->Audio->Misc’.
III.7 USB audio input
The codec might intake mono & stereo digital signals over the USB-AUDIO
interface (rear side). This signal might be mixed and routed as any other input
audio.
Optionally the user might assign /map gain knobs IN2 and IN3 to the digital
audio input control. Please follow the procedure:
1. access Menu->System->Function Keys
2. assign button F1 or F2 to
USB Audio Control
3. upon the activation of the selected function key
6
. IN2 and IN3 gain knobs
affects L & R of the digital audio input signal (USB-AUDIO)
Quantum USB-AUDIO interface is using 48kHz linear sampling.
Please remind changing any USB device or laptop to the matching
sampling frequency
6
Following activation of the function button returns the control of the IN2 and IN3 gain knobs to
the XLR analogue inputs
