Prodys S.L. Tel: +34 91 6896880 Fax: +34 91 6943777 Email: sales@prodys.net Web: www.prodys.com
Page 48
V.3 OUT audio output
Parameters
Value
Conditions
Max. Output Level
+12.2 dBu
0dBFs, Zload 100 kΩ, knob to 0 dB gain, 0dBFs
+11.6 dBu
0dBFs, Zload 300 Ω, knob to 0 dB gain, 0dBFs
Output level tolerance
±0.3 dB
Max. Output Power
90mWrms
75 load, clipping 997Hz test signal
Frequency response
-0.3 dB
20Hz-20 kHz, 300 load
Phase difference
20Hz-20 kHz
-1 dBFs 997Hz test signal
Zload 300
Crosstalk
>90 dB
Noise Level
<-90 dBu
Measured 22Hz to 20 kHz, knob to 0 dB gain
THD+N Ratio
> 93 dB
< 0.005%
Measured 22Hz to 20 kHz, knob to 0 dB gain
-1 dBFs 997Hz test signal.
Zload 300 .
Output impedance
24
V.4 USB Audio interface
V.4.1 USB Audio Input
1x stereo audio USB input /output port.
Connector: USB type B
USB 1.1.
Audio Input: PCM 16 bits 48 kHz sample rate (Host PC must be set
accordingly).
Audio Output: PCM 16 bits.
V.5 Compression
7
PCM
G722.
G711 A/μ Law.
7
Some compression modes are available as an option. Please contact sales@prodys.net for
more information.
