LINE ﺱﺑﺎﻗ ﻝﺎﺧﺩﺇ ﻡﺩﻋ ﺔﻟﺎﺣ ﻲﻓ .ﺭﺩﺎﺻﻣﻟﺍ ﻥﻣ ﻉﻭﻧ ﻝﻛ ﻥﻣ ﻥﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻭﺃ ﻥﺯﺍﻭﺗﻣ ﻁﺧ ﻯﻭﺗﺳﻣﺑ ﺓﺭﺎﺷﻹﺍ ﻝﻭﺑﻗ ﻰﻠﻋ ﺭﺩﺎﻗ ، jackﻝﺻﻭﻣ ﻪﻧﺇ
.2 ﺔﻁﻘﻧﻟﺍ ﻲﻓ ﺎﻬﺳﻔﻧ ﻲﻫ ﺕﺎﻳﺎﻬﻧﻟﺍ .ﺩﻳﺣﻭ ﺭﺩﺻﻣﻛ ﻝﺧﺩﻟﺍ ﺍﺫﻬﺑ MONO ﺓﺎﻧﻘﻛ ﺓﺎﻧﻘﻟﺍ ﻩﺫﻫ ﻝﻣﻌﺗ ﻑﻭﺳﻓ ،RIGHT
(ﻥﻳﻣﻳ ﻁﺧ ﻝﺧﺩﻣ) LINE RIGHT .14
ﺱﺑﺎﻗ ﺩﻭﺟﻭ ﻲﻓ ﻁﻘﻓ ﻡﺩﺧﺗﺳ
ُ
ﻳ .ﺭﺩﺎﺻﻣﻟﺍ ﻥﻣ ﻉﻭﻧ ﻝﻛ ﻥﻣ ﻥﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻭﺃ ﻥﺯﺍﻭﺗﻣ ﻁﺧ ﻯﻭﺗﺳﻣﺑ ﺓﺭﺎﺷﻹﺍ ﻝﻭﺑﻗ ﻰﻠﻋ ﺭﺩﺎﻗ ، jack ﻉﻭﻧ ﻥﻣ ﻝﺻﻭﻣ ﻪﻧﺇ
.STEREO ﻊﺿﻭ ﻲﻓ ﺓﺎﻧﻗ ﻡﺍﺩﺧﺗﺳﻻ LINE LEFT
(ﺏﺳﻛﻟﺍ ءﺎﻘﺗﻧﺍ ﺡﺎﺗﻔﻣ) GAIN -10/+4 .15
ﻡﺗﻳ (ﻝﺑﻳﺳﻳﺩ ﺓﺩﺣﻭ +4) ﺭﺯﻟﺍ ﻊﻓﺭ ﺔﻟﺎﺣ ﻲﻓ .ﻝﺛﻣﺃ ﻲﻠﺧﺍﺩ ﻯﻭﺗﺳﻣ ﻲﻓ ﻁﺑﺿﻟﺎﺑ ﺕﻻﻵﺍ ﺕﺍﺭﺎﺷﻹ ﺍﺫﻫ ﺢﻣﺳﻳ .ﻁﺧﻟﺍ ﻝﺧﺩﻣ ﺔﻳﺳﺎﺳﺣ GAIN ﺏﺳﻛﻟﺍ ﻡﻅﻧﻳ
.ﺔﺿﻔﺧﻧﻣ ﻁﺧ ﺕﺎﻳﻭﺗﺳﻣ ﻝﻭﺑﻘﻟ ﻝﺧﺩﻣﻟﺍ ﻁﺑﺿ ﻡﺗﻳ (ﻝﺑﻳﺳﻳﺩ ﺓﺩﺣﻭ-10) ﺭﺯﻟﺍ ﺽﻔﺧ ﺔﻟﺎﺣ ﻲﻓﻭ ،ﺔﻌﻔﺗﺭﻣ ﻁﺧ ﺕﺎﻳﻭﺗﺳﻣ ﻝﻭﺑﻘﻟ ﻝﺧﺩﻣﻟﺍ ﻁﺑﺿ
(pre-fader ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗﻟﺍ) AUX 1 .16
:ﺔﻅﺣﻼﻣ .ﺓﺎﻧﻘﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗـﻟﺍ ﻊﺿﻭ ﻰﻠﻋ ﺩﻣﺗﻌﺗ ﺎﻬﻧﺃ ﻲﻧﻌﻳ ﺎﻣﻣ ،pre-fader ﻲﻫ ﺓﺭﺎﺷﻹﺍ ﻩﺫﻫ .AUX 1 ﺝﺭﺧﻣﻟﺍ ﺩﻧﻋ ﺓﺭﺎﺷﻹﺍ ﻡﻛﺣﺗﻟﺍ ﺍﺫﻫ ﻝﺳﺭﻳ
.Mi12 ﻰﻠﻋ ﻁﻘﻓ ﺩﻭﺟﻭﻣ ﻡﻛﺣﺗﻟﺍ ﺍﺫﻫ
(FX ﻡﻳﻠﺳﺗﻟ post-fader ﻯﻭﺗﺳﻣ ﻡﻛﺣﺗ) (AUX 2 (Mi12) / AUX 1 (Mi10 .17
.(PROFEX digital effect processor) ﻲﻠﺧﺍﺩﻟﺍ ﺭﻳﺛﺄﺗﻟﺍ ﻰﻟﺇﻭ (AUX 2 (Mi12) / AUX 1 (Mi10 ﺝﺭﺧﻣﻟﺍ ﻰﻟﺇ ﺓﺭﺎﺷﺇ ﻡﻛﺣﺗﻟﺍ ﺍﺫﻫ ﻝﺳﺭﻳ
.ﺓﺎﻧﻘﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗـﻟﺍ ﻊﺿﻭ ﻰﻠﻋ ﺩﻣﺗﻌﺗ ﻯﺭﺧﺃ ﺓﺭﺎﺑﻌﺑ ﻭﺃ post-fader ﻲﻫ ﺓﺭﺎﺷﻹﺍ ﻩﺫﻫ
(ﻥﺯﺍﻭﺗﻟﺍ ﻲﻓ ﻡﻛﺣﺗﻟﺍ) BAL .18
ﺔﻟﺎﺣ ﻲﻓ ﺍﺭﺎﺳﻳﻭ ﺎﻧﻳﻣﻳ ﺓﺭﺎﺷﻹﺍ ﺔﻳﻣﻛ ﺽﻔﺧ ﻭﺃ ،MONO ﻲﻓ ﺔﻣﺩﺧﺗﺳﻣ ﺓﺎﻧﻘﻟﺍ ﺕﻧﺎﻛ ﺍﺫﺇ ﺎﻧﻳﻣﻳﻭ ﺍﺭﺎﺳﻳ ﺝﺭﺧﻣﻟﺍ ﻰﻟﺇ ﺎﻬﻟﺎﺳﺭﺇ ﺩﺍﺭﻣﻟﺍ ﺓﺭﺎﺷﻹﺍ ﺔﻳﻣﻛ ﻁﺑﺿﺍ
.STEREO ﻊﺿﻭ ﻲﻓ ﺓﺎﻧﻘﻟﺍ ﻡﺍﺩﺧﺗﺳﺍ
(ﺔﻣﻘﻟﺍ ﻑﺷﺎﻛ) PEAK .19
ﻝﺧﺩﻣﻟﺍ ﺓﺭﺎﺷﺇ ﻯﻭﺗﺳﻣ ﺽﻔﺧ ،LED PEAK ﺽﻳﻣﻭ ﺔﻟﺎﺣ ﻲﻓ :ﻡﺎﻫ .ﻩﻭﺷﺗﻟﺍ ﻥﻣ ﺔﺑﻳﺭﻗ ﻝﺧﺩﻟﺍ ﺓﺭﺎﺷﺇ ﻥﺃ ﻲﻧﻌﻳ ﺍﺫﻬﻓ LED PEAK ﺽﻳﻣﻭ ﺔﻟﺎﺣ ﻲﻓ
.GAIN ﺏﺳﻛﻟﺍ ﺭﺯ ﻡﺍﺩﺧﺗﺳﺎﺑ
(ﺓﺎﻧﻘﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗﻟﺍ) FADER LEVEL .20
.MAIN MIX ﺝﺭﺧﻣ ﻰﻟﺇ ﺎﻬﻠﺳﺭﻳﻭ ،ﺓﺎﻧﻘﻟﺍ ﺓﺭﺎﺷﺇ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(ﺭﻳﺛﺄﺗﻟﺍ ﺽﺭﻋﻭ ءﺎﻘﺗﻧﺍ ﺡﺎﺗﻔﻣ) PRESETS .21
ﻖﺑﺳﻣ ﺩﺍﺩﻋﺇ 16 ﻝﻣﺷﻳ .ﺕﺑ 24 ـﺑ AD/DA ﺕﻻﻭﺣﻣ ﻰﻠﻋﻭ ﻱﻭﻗ DSP ﻰﻠﻋ ﻡﺋﺎﻗ (PROFEX digital effect processor) ﻲﻠﺧﺍﺩﻟﺍ ﺭﻳﺛﺄﺗﻟﺍ
.ﺍﺭﻓﻭﺗﻣ ﺍﺭﻳﺛﺄﺗ 256 ﻲﻟﺎﻣﺟﻹ ﺕﻼﻣﺎﻌﻣﻟﺍ ﻥﻣ ﺍﺭﻳﻐﺗﻣ 16 ﺎﻬﻧﻣ ﻝﻛ ﺽﺭﻌﻳﻭ ،studio-grade ﺭﻳﺛﺄﺗ ﺕﺎﻳﻣﺯﺭﺍﻭﺧﺑ
:PROFEX ﺮﻴﺛﺄﺗ ﻡﺍﺪﺨﺘﺳﺍ ﺔﻴﻔﻴﻛ
؛ﻪﻣﺍﺩﺧﺗﺳﺍ ﺩﺍﺭﻣﻟﺍ (preset) ﺭﻳﺛﺄﺗﻟﺍ ﻉﻭﻧ ﺭﺎﻳﺗﺧﻻ ءﺎﻘﺗﻧﻻﺍ ﺡﺎﺗﻔﻣ ﺭﺩﺃ -
.ﺽﺭﻌﻟﺍ ﺔﺷﺎﺷ ﺽﻣﻭﺗ ﻰﺗﺣ ﺽﺑﻘﻣﻟﺍ ﻰﻠﻋ ﻝﻗﻷﺍ ﻰﻠﻋ ﻥﻳﺗﻳﻧﺎﺛﻟ ﻁﻐﺿﺍ ،preset ﺭﻳﻳﻐﺗ ﺩﻳﺩﺣﺗﻟ -
.ﺍﺭﻳﻳﻐﺗ 16 ﻥﻣ ﺍﺩﺣﺍﻭ ﺭﺎﻳﺗﺧﻻ ﺽﺑﻘﻣﻟﺍ ﺭﺩﺃ ﻡﺛ -
؛preset ﺩﻳﺩﺣﺗ ﻰﻟﺇ ﺓﺩﻭﻌﻟﺍﻭ ﺭﻳﻳﻐﺗﻟﺍ ﺩﻳﻛﺄﺗﻟ ﺽﻳﻣﻭﻟﺍ ﻥﻋ ﺔﺷﺎﺷﻟﺍ ﻑﻗﻭﺗﺗ ﻰﺗﺣ ﺽﺑﻘﻣﻟﺍ ﻰﻠﻋ ﻝﻗﻷﺍ ﻰﻠﻋ ﻥﻳﺗﻳﻧﺎﺛ ﺓﺩﻣﻟ ﺍﺩﺩﺟﻣ ﻁﻐﺿﺍ -
.ﺎﻬﻳﻟﺇ ﺭﻳﺛﺄﺗﻟﺍ ﺔﻓﺎﺿﺇ ﺩﺍﺭﻣﻟﺍ ﺓﺎﻧﻘﻠﻟ (AUX (9)(17 ﻡﻛﺣﺗﻟﺍ ﻡﺍﺩﺧﺗﺳﺎﺑ ﺭﻳﺛﺄﺗﻟﺎﺑ ﺓﺭﺎﺷﺇ ﻝﺳﺭﺃ -
.ﺭﻳﺛﺄﺗﻟﺍ ﻊﻣﺳﺗ ﻰﺗﺣ (FX LEVEL (24 ﺽﺑﻘﻣﻟﺍ ﻑﻟ -
.(23) ﺔﻣﻘﻠﻟ LED ﻰﻠﻋ ﺢﺿﻭﻣﻟﺍ ﺓﺭﺎﺷﻹﺍ ﻊﺑﺷﺗ ﻝﺑﻗ (AUX (9)(17 ﻡﻛﺣﺗﻟﺍ ﻁﺑﺿﺍ -
.ﺔﻳﻌﻳﺑﻁﻟﺍ ﺓﺭﺎﺷﻹﺍ ﻊﻣ ﺭﻳﺛﺄﺗﻟﺍ ﺓﺭﺎﺷﺇ ﻊﻣﺟﻟ FX LEVEL ﺽﺑﻘﻣﻟﺍ ﺍﺩﺩﺟﻣ ﻁﺑﺿﺍ -
.ﻁﻼﺨﻟﺍ ﻕﻼﻏﺇ ﺔﻟﺎﺣ ﻲﻓ ﺎﻀﻳﺃ ﺩﺪﺤﻤﻟﺍ ﺮﻴﻴﻐﺘﻟﺍﻭ ،preset ﺓﺮﻛﺍﺬﻟﺍ ﻲﻓ PROFEX ﻆﻔﺤﻳ :ﺔﻈﺣﻼﻣ
:preset ﻒﺻﻭ
ﺕﺍﺩﺩﺭﺗﺑ ﺓﺭﻳﺛﻛ ﺕﺎﺳﺎﻛﻌﻧﺍﻭ ﻝﻳﻭﻁ ﻝﻳﺫ ﻊﻣ ﺱﻧﺎﺟﺗﻣﻭ ﻱﻭﻗ ﻯﺩﺻ .ﺓﺭﻳﺑﻛ ﺕﻼﻔﺣ ﺔﻋﺎﻗ ﺔﺋﻳﺑ ﺯﻔﺣﻳ ﻯﺩﺻﻟﺍ ﻥﻣ ﻉﻭﻧﻟﺍ ﺍﺫﻫ - BRIGHT HALL .1 ﺹ
.ﺭﺎﺗﻭﻷﺍﻭ ﻲﺗﻭﺻﻟﺍﻭ ﻲﺋﺎﺑﺭﻬﻛﻟﺍ ﺭﺎﺗﻳﺟﻟﺍﻭ ،ﺕﺍﻭﺻﻸﻟ ﺏﺳﺎﻧﻣ .ﺔﻳﻟﺎﻋ
.[16] ﺓﺭﻳﻐﺻ ﻰﻟﺇ [1] ﺓﺭﻳﺑﻛ ﻥﻣ ،ﺔﻋﺎﻘﻟﺍ ﻡﺟﺣﻭ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻲﻓ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
ﺕﺍﺩﺩﺭﺗﺑ ﺔﻠﻳﻠﻗ ﺕﺎﺳﺎﻛﻌﻧﺍﻭ ﻝﻳﻭﻁ ﻝﻳﺫ ﻊﻣ ﺱﻧﺎﺟﺗﻣﻭ ﻱﻭﻗ ﻯﺩﺻ .ﺓﺭﻳﺑﻛ ﺕﻼﻔﺣ ﺔﻋﺎﻗ ﺔﺋﻳﺑ ﺯﻔﺣﻳ ﻯﺩﺻﻟﺍ ﻥﻣ ﻉﻭﻧﻟﺍ ﺍﺫﻫ - DARK HALL .2 ﺹ
.ﺦﻔﻧﻟﺍ ﺕﻻﺁﻭ ﺭﺎﺗﻳﺟﻟﺍﻭ ﺕﺍﻭﺻﻸﻟ ﺏﺳﺎﻧﻣ .ﺔﻳﻟﺎﻋ
.[16] ﺓﺭﻳﻐﺻ ﻰﻟﺇ [1] ﺓﺭﻳﺑﻛ ﻥﻣ ،ﺔﻋﺎﻘﻟﺍ ﻡﺟﺣﻭ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻲﻓ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
ﺓﺭﺛﻌﺑﻣﻟﺍﻭ ﺔﻌﻳﺭﺳﻟﺍ ﻰﻟﻭﻷﺍ ﺕﺎﺳﺎﻛﻌﻧﻻﺎﺑ ﺯﻳﻣﺗﻳ .ﺔﻋﺎﻘﻠﻟ ﺔﻳﻣﻳﻣﺣ ﺭﺛﻛﺃ ﺔﻳﺗﻭﺻ ﺔﺋﻳﺑ ﺝﺎﺗﻧﺇ ﻯﺩﺻﻟﺍ ﻥﻣ ﻉﻭﻧﻟﺍ ﺍﺫﻫ ﺩﻳﻌﻳ - BRIGHT ROOM .3 ﺹ
.ﺕﻼﺑﻁﻟﺍﻭ ،ﺔﻳﺭﺗﻭﻟﺍ ﺕﻻﻵﺍ ،ﺦﻔﻧﻟﺍ ﺕﻻﺁ ،ﺕﺍﻭﺻﻸﻟ ﺏﺳﺎﻧﻣ .ﺍﺩﺟ ﺔﻳﻟﺎﻋ ﺕﺍﺩﺩﺭﺗﺑ
.[16] ﺓﺭﻳﻐﺻ ﻰﻟﺇ [1] ﺓﺭﻳﺑﻛ ﻥﻣ ،ﺔﻓﺭﻐﻟﺍ ﻡﺟﺣﻭ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻲﻓ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
ﺓﺭﺛﻌﺑﻣﻟﺍﻭ ﺔﻌﻳﺭﺳﻟﺍ ﻰﻟﻭﻷﺍ ﺕﺎﺳﺎﻛﻌﻧﻻﺎﺑ ﺯﻳﻣﺗﻳ .ﺔﻋﺎﻘﻠﻟ ﺔﻳﻣﻳﻣﺣ ﺭﺛﻛﺃ ﺔﻳﺗﻭﺻ ﺔﺋﻳﺑ ﺝﺎﺗﻧﺇ ﻯﺩﺻﻟﺍ ﻥﻣ ﻉﻭﻧﻟﺍ ﺍﺫﻫ ﺩﻳﻌﻳ - DARK ROOM .4 ﺹ
.ﺕﻼﺑﻁﻟﺍﻭ ،ﻊﺑﺎﺻﻷﺍ ﺭﺎﺗﻳﺟ ،ﺕﺍﻭﺻﻸﻟ ﺏﺳﺎﻧﻣ .ﺔﻠﻳﻠﻗ ﺔﻳﻟﺎﻋ ﺕﺍﺩﺩﺭﺗﺑ
.[16] ﺓﺭﻳﻐﺻ ﻰﻟﺇ [1] ﺓﺭﻳﺑﻛ ﻥﻣ ،ﺔﻓﺭﻐﻟﺍ ﻡﺟﺣﻭ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻲﻓ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﻝﻳﻭﻁ ﻝﻳﺫﺑ ﺕﺍﻭﺻﻸﻟ ﺏﻟﻭﻘﻣ ﻯﺩﺻ - (VOCAL 1 (STAGE REVERB .5 ﺹ
.hall ﻭﺃ plate, spring ﻯﺩﺻﻟ ﺔﻋﻭﻧﺗﻣﻟﺍ ﻁﺎﻣﻧﻷﺍ ﺭﻳﻳﻐﺗ ﻊﻣ [16] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﻥﻣ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻥﻣ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﻱﻭﻗ ﻝﻳﺫﺑ ﺕﺍﻭﺻﻸﻟ ﺏﻟﻭﻘﻣ ﻯﺩﺻ - (VOCAL 2 (CLUB REVERB .6 ﺹ
.spring ﻭﺃ tape, hall ﻯﺩﺻﻟ ﺔﻋﻭﻧﺗﻣﻟﺍ ﻁﺎﻣﻧﻷﺍ ﺭﻳﻳﻐﺗ ﻊﻣ [16] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﻥﻣ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻥﻣ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﺕﺎﻧﻳﻧﺎﻣﺛﻟﺍﻭ ﺕﺎﻧﻳﻌﺑﺳﻟﺍ ﻲﻓ ﺕﻼﻳﺟﺳﺗﻟﺍ ﻲﻓ ﻡﺩﺧﺗﺳﻣ "plate" ﻲﻛﻳﺳﻼﻛ ﻯﺩﺻﻟ ﺓﺎﻛﺎﺣﻣ ﻩﺫﻫ - PLATE .7 ﺹ
.[16] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﻥﻣ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻥﻣ ﺕﺎﻳﻋﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﻰﻧﻣﻳﻭ ﻯﺭﺳﻳ ﺕﺍﻭﻧﻗ ﻰﻠﻋ ﻎﻧﻭﺑ-ﻎﻧﻳﺑﻟﺍ ﻊﻣ ﻯﺩﺻﻟﺍ ﺭﻳﺛﺄﺗ - STEREO DELAY .8 ﺹ
.[2] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﺭﺍﺭﻛﺗ ﺕﻗﻭ ﻥﻣ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺃﺩﺑﺗ
